Processor | Intel? 11th TigerLakeCore? i3 / i5 / i7 – U/H SOC Processor TDP：35W |
Memory | 2 * DDR4 3200 MHz SO-DIMM / Max：64G |
Storage | 1 * M.2 2280 SSD NVME or SATA / 1 * SATA 3.0 Port |
Graphics | Intel? Iris? Xe Graphics |
Wireless | 1 * M.2 2230 WIFI/BT Module |
Network | Realtek Gigabit Ethernet |
Audio | Realtek ALC897 Audio |
I/O Interfaces | 4 * USB3.2 Type-A 1 * Line out 1 * Mic in 1 * VGA @ 1920*1080 1 * HDMI @ 4096*2160 1 * DC Jack |
Internal Interfaces | 2 * F-USB 2.0 pin 1 * 30 Pin LVDS pin 1 * SATA 3.0 Port 1 * F-Audio pin 1 * SPEAK 1 * 4Pin Fan 1 * 4 PIN Power 1 * RS232 COM（Optional） |
Power input | 12V / 19V DC in |
Dimension | 170 * 170 mm |
Working enviroment | Operating 0℃~45℃ Storage -20℃~70℃ |
Relative humidity | 10%~95% （non-condensing） |
