Processor | Intel? H510 ChipsSet sustain Intel? 12-13 th Core I3-I7 CPU TDP 65W |
model | OPS-TC-OC61S |
Graphics | Intel? UHD Graphics series |
Memory | 2 * SO-DIMM * 3200 DDR4 |
Storage | 1*M.2 SATA SSD or NVME / 1 * 2.5” SATA HDD/SSD |
Display interface | HDMI 1.4 * 1 / DP 1.2 *1 |
Network | 1000M LAN * 1 |
USB | USB3.0 * 3 / USB2.0 * 3 |
Audio | Mic in*1 / 3.5mm Line out*1 |
Machine key | Power button*1 / Power LED*1 / reset *1& C _CMOS*1 |
Wireless | 1* M.2 2230 WIFI+BT |
Expansion interface | Mini PCI-E/mSata （Default without SSD） |
OPS interface | 1*JAE 80PIN（1*HDMI 1.4 OUT / 3*USB2.0 / TTL） |
fan | Intelligent speed regulation |
operating system | Windows 10 、11 / Linux |
Working enviroment | -5°C ~45°C / 30% ~ 98% RH |
Power input | DC 19 V |
Dimension | 195mm * 180mm *42 / 30mm |
